GE MEDICAL SYSTEMS
DIRECTION 2300000, REVISION 2 LOGIQ™5 SERVICE MANUAL
8-200 Section 8-11 - Installing Base Software Load Image
8-11-3-3 Functional Checks for Service Platform (Diagnostic Program) (cont’d)
3.) The Service Login window for Service Platform will be shown on the monitor display.
4.) Select GE Service at the “Select User Level” field.
5.) Enter the password for the Service Platform.
6.) Click on Okay.
7.) Verify that the following screen (Service Platform) is displayed on the monitor.
Figure 8-253 Service Login Window
CAUTION
If the Login window for Service Platform is not displayed on the monitor, the installation of the
Service Platform has failed. Reload the application software or Base System Software (OS) +
application software. Contact a Technical Support for details.
Figure 8-254 Select GE Service
NOTICE
When the service platform is NOT displayed, check if CAPS lock is selected. The CAPS should not be
selected.
