Pin Assignment
Pin Assignment of DC in put
Connector: 4 Pin, Female
Pin Assignment of USB1
Pin Assignment of USB2
Pin Assignment of USB3
Table 3-5: Pin Assignment of DC input
Pin No. Signal Pin No. Signal
1+20V3GND
2+20V4GND
Table 3-6: Pin Assignment of USB1
Pin No. Signal Pin No. Signal
1+5VDC3DATA+
2DATA-4GND
Table 3-7: Pin Assignment of USB2
Pin No. Signal Pin No. Signal
1+5VDC3DATA+
2DATA-4GND
Table 3-8: Pin Assignment of USB3
Pin No. Signal Pin No. Signal
1+5VDC3DATA+
2DATA-4GND
