Renewal Parts
LOGIQ e – Basic Service Manual
12-19
5461614-100
English Rev. 6
Shelf Service
T
a
ble
12-8:
Shelf Ser
vice
Item
Part
Number
Part Name
Corresponding graphic
Qty
900
5255346-2
Support shelf with package
1
901
5219976-2
S
torage Ra
ck
1
902
5255345-2
Peripheral shelf with package
1
903
5423171-2
T
op DVD Shelf Assy
1
402
404
Table of Contents
