Renewal Parts
LOGIQ e – Basic Service Manual
12-15
5461614-100
English Rev. 6
Docking St
ation
T
able
12-6:
Docking S
tation
Item
Part
Number
Part Name
Corresponding graphic
Qty
700
5422689-2
LOGIQ e T
op Support
1
701
5423180-2
LOGIQ e DS T
op Cover Assy
1
702
5423191-2
LOGIQ e DS Main PW
A
1
703
5444585
LOGIQ e Multiport board
cable
1
398
400
