Product icons
LOGIQ e – Basic Service Manual 1-13
5461614-100 English Rev. 6
General Warning. Various
“CAUTION” - Dangerous
voltage” (the lightning flash with
arrowhead) is used to indicate
electric shock hazards.
Various
“ON” indicates the power on
position of the power switch.
CAUTION: This Power Switch
DOES NOT ISOLATE Mains
Supply.
See the Console
Overview section for
location information.
“Protective Earth” indicates the
protective earth (grounding)
terminal.
Inside of AC adapter
NRTL Listing and Certification
Mark is used to designate
conformance to nationally
recognized product safety
standards. The Mark bears the
name and/or logo of the testing
laboratory, product category,
safety standard to which
conformity is assessed and a
control number.
Bottom
Type CF Defib-Proof Applied
Part (heart in the box with
paddle) symbol is in accordance
with IEC 60878-02-06.
ECG Module
“Consult accompanying
documents“ is intended to alert
the user to refer to the operator
manual or other instructions
when complete information
cannot be provided on the label.
Various
Do not push the system. Rear of Docking Cart/
Isolation Cart
Table 1-5: Product Icons (Continued)
Label/Icon Purpose/Meaning Location
