MENU TEXT Col Row Default Setting Available Setting
Description
SAV No SmpSynch 18 52 00000000
This is a data cell with 8 binary flags. It indicates the healthiness of the Sampled Values being received from each of the
configured Merging Units.
0: Sampled Values received are synchronised and any loss of samples is within acceptable limits.
1: Sampled Values received are not synchronised (Setting :Synchro Alarm) or the Sampled Value delay exceeds the acceptable
value (Merging Unit Delay setting). The IED raises a 9-2 Sample Alarm when any one of the binary flags is 1.
SAV Questionable 18 54
00000000 00000000
00000000
This is a data cell with 24 binary flags. It indicates the status of the IEC 61850 Quality attribute ‘Questionable’ in the Sampled
Value frames for each of the analogue channels. The channel assignment depends on the IED.
SAV Invalid 18 55
00000000 00000000
00000000
This is a data cell with 24 binary flags. It indicates the status of the IEC 61850 Quality attribute ‘Invalid’ in the Sampled Value
frames for each of the analogue channels. The channel assignment depends on the IED.
4.6.1.2 ALARM SIGNALS DDB TABLE
Ordinal Signal Name Source Type Response
Description
340 ALARM_9_2_SAV Software PFSO Self reset alarm
Sampled Value error.
341 GLOBAL_SYN_FAIL Software PFSO
Alarm latched with protection
function
This alarm is raised if the global synchronisation for Sampled Values has failed, inhibiting the current differential function.
342 9_2_SAV_CFG_ALARM Software PFSO Self reset alarm
This alarm is triggered when the LN name is less than 10 characters or greater than 34 characters.
343 ALARM_INV_SETTING_SAV Software PFSO Self reset alarm
This alarm is raised if Phase Diff is set to Enabled but GPS Sync is set to GPS disabled.
P446SV Chapter 6 - Sampled Value Operation
P446SV-TM-EN-1 103
