IED IED IED

K-BusRS232

KITZ protocol converterRS232-USB converterComputer

V01001

Figure 267: Remote communication using K-Bus

Note:

An RS232-USB converter is only needed if the local computer does not provide an RS232 port.

Further information about K-Bus is available in the publication R6509: K-Bus Interface Guide, which is available on

request.

P446SV Chapter 21 - Communications

P446SV-TM-EN-1 509
