Address Name Trigger Trap?
1 Date Time NO
2 IRIG-B Status YES
3 Battery Status YES
4 Active Sync source YES
5 SNTP Server 1 NO
6 SNTP Server 2 NO
7 SNTP Status YES
8 PTP Status YES
3 System Alarms
1 Invalid Message Format YES
2 Main Protection Fail YES
3 Comms Changed YES
4 Max Prop. Alarm YES
5 9-2 Sample Alarm YES
6 9-2LE Cfg Alarm YES
7 Battery Fail YES
8 Rear Communication Fail YES
9 GOOSE IED Missing YES
10 Intermicom loopback YES
11 Intermicom message fail YES
12 Intermicom data CD fail YES
13 Intermicom Channel fail YES
14 Backup setting fail YES
15 User Curve commit to flash failure YES
16 SNTP time Sync fail YES
17 PTP failure alarm YES
4 Device Mode
1 IED Mod/Beh YES
2 Simulation Mode of Subscription YES
6.3 REDUNDANT ETHERNET BOARD MIB STRUCTURE
The Redundant Ethernet board MIB uses three types of OID:
● sysDescr
● sysUpTime
● sysName
MIB structure for RSTP, DHP and SHP
Address
Name
0 CCITT
1 ISO
3 Org
6 DOD
1 Internet
