DDB Signal Name DDB Signal Number Source Module (Module Number) Destination Module (Module Number.)
CB2 Ext Trip B 540
CB2 1-pole / 3-pole trip (14)
CB1 AR In Progress (16)
CB2 AR In Progress (17)
CB Control (44)
CB2 Ext Trip C 541
CB2 1-pole / 3-pole trip (14)
CB1 AR In Progress (16)
CB2 AR In Progress (17)
CB Control (44)
CB2 Ext Trip3ph 538
CB2 1-pole / 3-pole trip (14)
CB1 AR In Progress (16)
CB2 AR In Progress (17)
CB Control (44)
CB2 Fail Pr Trip 1459 CB2 Trip Time Monitor (54)
Autoreclose Lockout (55)
CB2 Autoreclose Lockout (56)
CB2 Failed AR 1441 Evolving Fault (20)
CB2 Fast SCOK 1454
3 Phase AR System Check Leader CB2 (46)
3 Phase AR System Check Follower CB2 (48)
CB2 Autoclose (33)
CB2 Healthy and System Check Timers (40)
CB2 Healthy 437
CB Autoclose (32)
CB2 Healthy and System Check Timers (40)
CB Control (44)
CB2 In Service 1428 CB In Service (4)
Leader Follower Logic (8)
Autoreclose Lockout (55)
CB2 Autoreclose Lockout (56)
Leader Follower Logic (7)
CB2 Lead 1408 Leader/Follower CB Selection (6)
CB2 LO Alarm 1599
CB2 AR In Progress (17)
Pole Discrepancy (62)
CB2 Man SCOK 1458 CB2 Manual Close System Check (52) CB Control (44)
CB2 NoAR 1429
Leader Follower Logic (8)
Leader Follower Logic (7)
CB2 AR In Progress (17)
Leader Follower Logic (7)
CB2 Open 3 ph 911 CB2 State Monitor (2)
CB Open (3)
Dead Time Start Enable (22)
Follower 3-phase CB AR Time (29)
CB2 Autoclose (33)
CB Control (44)
CB2 Trip Time Monitor (54)
CB2 Open A ph 912 CB2 State Monitor (2)
CB Open (3)
CB Control (44)
Pole Discrepancy (62)
CB2 Open B ph 913 CB2 State Monitor (2)
CB Open (3)
CB Control (44)
Pole Discrepancy (62)
CB2 Open C ph 914 CB2 State Monitor (2)
CB Open (3)
CB Control (44)
Pole Discrepancy (62)
CB2 Status Alm 323 CB2 State Monitor (2) CB2 Autoreclose Lockout (56)
CB2 Succ 1P AR 1451 Successful AR Signals (36) CB2 AR Shot Counters (42)
CB2 Succ 3P AR 1452 Successful AR Signals (36) CB2 AR Shot Counters (42)
CB2 Trip 3ph 1600 CB Trip Conversion (63)
CB2 Trip AR MemA 1499 CB2 1-pole / 3-pole Trip (13) CB2 1-pole / 3-pole Trip (13)
