GE Power Quality Meter Series User Manual

7-38 PQM Power Quality Meter GE Power Management
7.3 MODBUS MEMORY MAP 7 MODBUS COMMUNICATIONS
7
EVENT
RECORD
continued
0AE0 Record #N Event Number --- --- --- F1 N/A
0AE1 Record #N Event Cause --- --- --- F36 0 = NO EVENT
0AE2 Record #N Time - Hours/Minutes --- --- --- F22 N/A
0AE3 Record #N Time - Seconds --- --- --- F23 N/A
0AE4 Record #N Date - Month/Day --- --- --- F24 N/A
0AE5 Record #N Date - Year --- --- --- F25 N/A
0AE6 Record #N Switches and Relays States --- --- --- F111 N/A
0AE7 Record #N Ia --- --- A F1 N/A
0AE8 Record #N Ib --- --- A F1 N/A
0AE9 Record #N Ic --- --- A F1 N/A
0AEA Record #N In --- --- A F1 N/A
0AEB Record #N I Unbalance --- --- 0.1 x% F1 N/A
0AEC Record #N Van (high) --- --- V F3 N/A
0AED Record #N Van (low) --- --- V F3 N/A
0AEE Record #N Vbn (high) --- --- V F3 N/A
0AEF Record #N Vbn (low) --- --- V F3 N/A
0AF0 Record #N Vcn (high) --- --- V F3 N/A
0AF1 Record #N Vcn (low) --- --- V F3 N/A
0AF2 Record #N Vab (high) --- --- V F3 N/A
0AF3 Record #N Vab (low) --- --- V F3 N/A
0AF4 Record #N Vbc (high) --- --- V F3 N/A
0AF5 Record #N Vbc (low) --- --- V F3 N/A
0AF6 Record #N Vca (high) --- --- V F3 N/A
0AF7 Record #N Vca (low) --- --- V F3 N/A
0AF8 Record #N V Unbalance --- --- 0.1 x% F1 N/A
0AF9 Record #N Pa (high) --- --- 0.01 x kW F4 N/A
0AFA Record #N Pa (low) --- --- 0.01 x kW F4 N/A
0AFB Record #N Qa (high) --- --- 0.01 x kvar F4 N/A
0AFC Record #N Qa (low) --- --- 0.01 x kvar F4 N/A
0AFD Record #N Sa (high) --- --- 0.01 x kVA F3 N/A
0AFE Record #N Sa (low) --- --- 0.01 x kVA F3 N/A
0AFF Record #N PFa --- --- 0.01 x PF F2 N/A
0B00 Record #N Pb (high) --- --- 0.01 x kW F4 N/A
0B01 Record #N Pb (low) --- --- 0.01 x kW F4 N/A
0B02 Record #N Qb (high) --- --- 0.01 x kvar F4 N/A
0B03 Record #N Qb (low) --- --- 0.01 x kvar F4 N/A
0B04 Record #N Sb (high) --- --- 0.01 x kVA F3 N/A
0B05 Record #N Sb (low) --- --- 0.01 x kVA F3 N/A
0B06 Record #N PFb --- --- 0.01 x PF F2 N/A
0B07 Record #N Pc (high) --- --- 0.01 x kW F4 N/A
0B08 Record #N Pc (low) --- --- 0.01 x kW F4 N/A
0B09 Record #N Qc (high) --- --- 0.01 x kvar F4 N/A
0B0A Record #N Qc (low) --- --- 0.01 x kvar F4 N/A
0B0B Record #N Sc (high) --- --- 0.01 x kVA F3 N/A
Table 7–10: PQM MEMORY MAP (Sheet 24 of 40)
GROUP ADDR
(HEX)
DESCRIPTION RANGE STEP
VALUE
UNITS and
SCALE
FORMAT FACTORY DEFAULT
Notes: * Data type depends on the Command Operation Code. ** Any valid Actual Values or Setpoints address.
*** Maximum Setpoint value represents “OFF”. **** Minimum Setpoint value represents “OFF”.
***** Maximum Setpoint value represents “UNLIMITED”.
