GE Power Management PQM Power Quality Meter 7-61
7 MODBUS COMMUNICATIONS 7.3 MODBUS MEMORY MAP
7
F107
con’t
Analog Input Alt Alarm 0040
Data Log 1 0080
Data Log 2 0100
Negative Real Power Demand alarm 0200
Negative Reactive Power Demand Alarm 0400
Pulse Input 2 Alarm 0800
Pulse Input 3 Alarm 1000
Pulse Input 4 Alarm 2000
Totalized Pulse Input Alarm 4000
Time Alarm 8000
F108 INTERNAL FAULT ERROR CODE FFFF
ADC Reference Out of Range 0001
HC705 Processor Not Responding 0002
Switch Input Circuit Fault 0004
HC705 MOR Byte is Not Programmed 0008
Not Used 0010
Not Used 0020
Not Used 0040
Not Used 0080
Not Used 0100
Not Used 0200
Not Used 0400
Not Used 0800
Not Used 1000
Not Used 2000
Not Used 4000
Not Used 8000
F109 GENERAL STATUS FFFF
Alarm Present 0001
Clock Not Set 0002
Clock Drifting 0004
Data Log 1 Running 0008
Data Log 2 Running 0010
Not Used 0020
Not Used 0040
Not Used 0080
Not Used 0100
Not Used 0200
Not Used 0400
Not Used 0800
Not Used 1000
Not Used 2000
Not Used 4000
Not Used 8000
F110 DATA LOGGER NUMBERS FFFF
Log 1 0001
Log 2 0002
Table 7–11: MEMORY MAP DATA FORMATS (Sheet 13 of 16)
CODE DESCRIPTION BITMASK
F110
con’t
Not Used 0004
Not Used 0008
Not Used 0010
Not Used 0020
Not Used 0040
Not Used 0080
Not Used 0100
Not Used 0200
Not Used 0400
Not Used 0800
Not Used 1000
Not Used 2000
Not Used 4000
Not Used 8000
F111 EVENT RECORD SWITCHES AND RELAY STATUS FFFF
Alarm Relay 0001
Auxiliary Relay 1 0002
Auxiliary Relay 2 0004
Auxiliary Relay 3 0008
Not Used 0010
Not Used 0020
Not Used 0040
Not Used 0080
Switch A 0100
Switch B 0200
Switch C 0400
Switch D 0800
Not Used 1000
Not Used 2000
Not Used 4000
Not Used 8000
F112 EVENT RECORDER EVENT ENABLE FLAGS 4 FFFF
Power On 0001
Power Off 0002
Alarm / Control Reset 0004
Setpoint Access Enable 0008
Not Used 0010
Not Used 0020
Not Used 0040
Not Used 0080
Not Used 0100
Not Used 0200
Not Used 0400
Not Used 0800
Not Used 1000
Not Used 2000
Not Used 4000
Table 7–11: MEMORY MAP DATA FORMATS (Sheet 14 of 16)
CODE DESCRIPTION BITMASK
