GE Power Management PQM Power Quality Meter 8-13
8 DNP COMMUNICATIONS 8.1 DNP 3.0 PROTOCOL
8
137 0487 Voltage Vbn THD - Maximum 0.1 x % 1 unit F1 3
138 0488 Voltage Vcn THD - Maximum 0.1 x % 1 unit F1 3
139 0489 Voltage Vab THD - Maximum 0.1 x % 1 unit F1 3
140 048A Voltage Vbc THD - Maximum 0.1 x % 1 unit F1 3
141 048B Voltage Vca THD - Maximum 0.1 x % 1 unit F1 3
142 04C8 ADC Reference - 20 units F1 2
143 04C9 Power Loss Fine Time 10 ms 1 unit F1 2
144 04CA Power Loss Coarse Time 0.1 min. 1 unit F1 2
145 04CB Current Key Press - 1 unit F8
5
2
146 04CC Internal Fault Error Code - 1 unit F108 2
147 0000 Multilin Product Device Code always 65 - F1 -
148 0001 Hardware Version Code - - F5 -
149 0002 Main Software Version Code - - F1 -
150 0003 Modification File Number 1 - - F1 -
151 0004 Boot Software Version Code - - F1 -
152 0005 Supervisor Processor Version Code - - F1 -
153 0007 Modification File Number 2 - - F1 -
154 0008 Modification File Number 3 - - F1 -
155 0009 Modification File Number 4 - - F1 -
156 000A Modification File Number 5 - - F1 -
157 0020 Serial Number Character 1 and 2 - - F10 -
158 0021 Serial Number Character 3 and 4 - - F10 -
159 0022 Serial Number Character 5 and 6 - - F10 -
160 0023 Serial Number Character 7 and 8 - - F10 -
161 0030 Manufacture Month/Day - - F24 -
162 0031 Manufacture Year - - F25 -
163 0032 Calibration Month/Day - - F24 -
164 0033 Calibration Year - - F25 -
1. This point is used to reconstruct neutral current values from the 1,000ths per-unit quantities given in the other points.
Multiply the particular point by this one, and divide by 1000 to get amps.
2. The VT Ratio setpoint is always reported, but is not used if a direct (i.e., without VTs) voltage wiring scheme is config-
ured. In this case the VT Ratio setpoint is ignored, and a ratio of 1.0:1 is used in the PQM.
3. This point is used to reconstruct voltage values from the 1,000ths per-unit quantities given in the other points. Multiply
the particular point by this one, and divide by 1000 to get volts. Since some SCADA systems don’t read 32 bit values,
you can also multiply the VT ratio and nominal secondary (both of which are 16 bit) in the master in cases where the
nominal primary may exceed 32767 volts.
4. This point is used to reconstruct power values from the 1,000ths per-unit quantities given in the other points. Multiply
the particular point by this one, and divide by 1000 to get VA, kW or kvar.
5. In Modbus, the current keypress is reported with format code F6. In order to fit the value into a sixteen-bit signed
value, F8 is used in DNP, with ASCII zero (49 decimal) returned when no key is pressed.
Table 8–1: POINT LIST FOR ANALOG INPUT/OUTPUT CHANGE (Sheet 5 of 5)
POINT MOBUS
REG
DESCRIPTION UNIT / VALUE DEADBAND FORMAT
CODE
EVENT CLASS
ASSIGNED TO
see footnote explanations at the end of the table
