GE Power Quality Meter Series User Manual

8-12 PQM Power Quality Meter GE Power Management
8.1 DNP 3.0 PROTOCOL 8 DNP COMMUNICATIONS
8
100 031C Phase A Reactive Power Minimum 1000ths of nominal 1 unit F4 3
101 031E Phase A Apparent Power Minimum 1000ths of nominal 1 unit F3 3
102 0220 Phase A Power Factor - Minimum % 1 unit F2 3
103 0321 Phase A Real Power - Maximum 1000ths of nominal 1 unit F4 3
104 0323 Phase A Reactive Power Maximum 1000ths of nominal 1 unit F4 3
105 0325 Phase A Apparent Power Maximum 1000ths of nominal 1 unit F3 3
106 0327 Phase A Power Factor Maximum % 1 unit F2 3
107 0328 Phase B Real Power Minimum 1000ths of nominal 1 unit F4 3
108 032A Phase B Reactive Power Minimum 1000ths of nominal 1 unit F4 3
109 032C Phase B Apparent Power Minimum 1000ths of nominal 1 unit F3 3
110 032E Phase B Power Factor Minimum % 1 unit F2 3
111 032F Phase B Real Power Maximum 1000ths of nominal 1 unit F4 3
112 0331 Phase B Reactive Power Maximum 1000ths of nominal 1 unit F4 3
113 0333 Phase B Apparent Power Maximum 1000ths of nominal 1 unit F3 3
114 0335 Phase B Power Factor Maximum % 1 unit F2 3
115 0336 Phase C Real Power Minimum 1000ths of nominal 1 unit F4 3
116 0338 Phase C Reactive Power Minimum 1000ths of nominal 1 unit F4 3
117 033A Phase C Apparent Power -
Minimum
1000ths of nominal 1 unit F3 3
118 033C Phase C Power Factor Minimum % 1 unit F2 3
119 033D Phase C Real Power Maximum 1000ths of nominal 1 unit F4 3
120 033F Phase C Reactive Power Maximum 1000ths of nominal 1 unit F4 3
121 0341 Phase C Apparent Power Maximum 1000ths of nominal 1 unit F3 3
122 0343 Phase C Power Factor Maximum % 1 unit F2 3
123 040A Phase A Current Demand Maximum 1000ths of nominal 1 unit F1 3
124 040B Phase B Current Demand Maximum 1000ths of nominal 1 unit F1 3
125 040C Phase C Current Demand Maximum 1000ths of nominal 1 unit F1 3
126 040D Neutral Current Demand Maximum 1000ths of nominal 1 unit F1 3
127 040E 3 Phase Real Power Dmd Max 1000ths of nominal 1 unit F4 3
128 0410 3 Phase React Power Dmd Max 1000ths of nominal 1 unit F4 3
129 0412 3 Phase Apparent Power Dmd Max 1000ths of nominal 1 unit F3 3
130 0441 Frequency Minimum 0.01x Hz .01 Hz F1 3
131 0442 Frequency Maximum 0.01x Hz .01 Hz F1 3
132 0482 Phase A Current THD - Maximum 0.1 x % 1 unit F1 3
133 0483 Phase B Current THD - Maximum 0.1 x % 1 unit F1 3
134 0484 Phase C Current THD - Maximum 0.1 x % 1 unit F1 3
135 0485 Neutral Current THD - Maximum 0.1 x % 1 unit F1 3
136 0486 Voltage Van THD - Maximum 0.1 x % 1 unit F1 3
Table 8–1: POINT LIST FOR ANALOG INPUT/OUTPUT CHANGE (Sheet 4 of 5)
POINT MOBUS
REG
DESCRIPTION UNIT / VALUE DEADBAND FORMAT
CODE
EVENT CLASS
ASSIGNED TO
see footnote explanations at the end of the table
