GE Power Management PQM Power Quality Meter 9-3
9 COMMISSIONING 9.1 COMMISSIONING
9
S2 SYSTEM SETUP continued
SWITCH INPUT C
SWITCH C NAME
SWITCH C FUNCTION
SWITCH C ACTIVATION
SWITCH C TIME DELAY sec.
SWITCH INPUT D
SWITCH D NAME
SWITCH D FUNCTION
SWITCH D ACTIVATION
SWITCH D TIME DELAY sec.
PULSE OUTPUT
POS kWh PULSE OUTPUT RELAY
POS kWh PULSE OUTPUT INTERVAL kWh
NEG kWh PULSE OUTPUT RELAY
NEG kWh PULSE OUTPUT INTERVAL kWh
POS kvarh PULSE OUTPUT RELAY
POS kvarh PULSE OUTPUT INTERVAL kvarh
NEG kvarh PULSE OUTPUT RELAY
NEG kvarh PULSE OUTPUT INTERVAL kvarh
kVAh PULSE OUTPUT RELAY
kVAh PULSE OUTPUT INTERVAL kVAh
PULSE WIDTH
PULSE INPUT
PULSE INPUT UNITS
PULSE INPUT 1 VALUE
PULSE INPUT 2 VALUE
PULSE INPUT 3 VALUE
PULSE INPUT 4 VALUE
PULSE INPUT ADDITION
Table 9–1: PQM SETPOINTS (Sheet 5 of 11)
S3 OUTPUT RELAYS
ALARM RELAY
ALARM OPERATION
ALARM ACTIVATION
AUXILIARY RELAY 1
AUX1 OPERATION
AUX1 ACTIVATION
AUXILIARY RELAY 2
AUX2 OPERATION
AUX2 ACTIVATION
AUXILIARY RELAY 3
AUX3 OPERATION
AUX3 ACTIVATION
Table 9–1: PQM SETPOINTS (Sheet 6 of 11)
