2026116-001 Revision B Responder™ 2000 Page 121
ECG MONITORING
Detection Lead: Through either 3-lead and 5-lead patient cable, pads, or paddles
Lead Selection:
3-Lead Cable: (I, II, III) and 5-Lead (I, II, III, aVL,aVR, aVF, and V), PADS:
(Modified Lead II)
Heart Rate Range: 25 to 300 bpm
Display Frequency Response (ECG Leads): 0.5 to 100 Hz (± 10 %)
Display Frequency Response (paddles): 3 Hz to 33 Hz (± 10 %); (-3db)
ECG Effective Sampling Rate: 1000 samples per second (ECG Leads), 128 samples per second (paddles)
Post Defibrillation Recovery: 8 seconds
Low Heart Rate Alarms: Off, 25-120 bpm
High Heart Rate Alarms: Off, 40-300 bpm
ECG Leads and paddles leakage current Less than 10uA in normal; Less than 50uA in single fault condition
Dynamic Range: Input ECG signal amplitude: ± 5mV
Dynamic Range: DC Offset voltage: ± 500 mV ECG from ECG cable; ± 1000 mV (ECG from pads, paddles and
spoons
Asystole Threshold 0.2mV (±0.1mV)
RECHARGEABLE BATTERY
Battery Voltage: 11.1 V Nominal
Chemistry: Lithium-ion
Compatibility: Compatible with Responder 2000
Battery Capacity: 50 shocks, or 240 minutes monitoring time, or 72 minutes monitoring time
with pacing
Battery Charge Time: 8 hours in Responder 2000, 4 hours in external charger, 20 hours for
calibration cycle in external charger
Battery Standby: 6 months
Battery Life: 2.5 years or 300 Battery charge-discharge cycles, whichever comes first
Battery Weight: 1 lb. 3 oz; .54 kg
AC POWER SUPPLY
Universal input: 100V to 240V~
50Hz-60Hz
200VA
PRINTER
Speed 25 mm/s feed rate
Paper Size 60 mm paper width
