2026116-001 Revision B Responder™ 2000 Page 90
CHANNEL 1
The Channel 1 menu allows default settings to be selected for Source and Gain.
Source Auto-switch Source
Factory Default: ECG II
Available Settings: ECG 1, ECG II, ECG III, aVR, aVF, aVL,
V, Paddles
Factory Default: Off
Available Settings: On, Off
Gain
Factory Default: 1x
Available Settings: .25x, 0.5x, 1x, 2x, 4x
CHANNEL 2
The Channel 2 menu allows default settings to be selected for Source and Gain.
Source Gain
Factory Default: SpO
2
with Option, Otherwise Cascade
Available Settings: Cascade, SpO
2
Factory Default: 1x
Available Settings: .25x, 0.5x, 1x, 2x, 4x
FILTERS
The Filters menu allows default settings to be selected for Line Filter (Hz) and Muscle Filter.
Selection only valid for ECG channel, but not for pads/paddles channel.
Line Filter (Hz) Muscle Filter
Factory Default: Off
Available Settings: Off, 50, 60
Factory Default: On
Available Settings: On, Off
Always On, if pads/paddles selected.
