ADV200 • Quick start up guide 103
22.13.4 3176 Brake open spd thr
Setting of the brake opening speed threshold
value
0
Based on customer
application
22.13.5 3178 Brake close spd thr
Setting of the brake closing speed threshold
value
0
Based on customer
application
22.13.6 3182 Brake open thr sel
Selection of the type of comparison between
the brake opening threshold value and the
torque or current value.
Output curr
Torque ref%
(for Flux vector OL
and Flux vector CL)
22.13.7 3184 Brake open thr
Value of the threshold at which the comparison
is made
10
Based on customer
application
22.13.8 3186 Brake open thr src
Selection of the origin (source) of the signal to
be used
PAR 3184
Based on customer
application
• Basic settings to control asynchronous multi-windings motor
Through two separate inverters in Master-Slave conguration, it is possible to
control only motors with separate windings, isolated and in phase with each other.
For this operating mode, only the “Flux vector CL” operating mode is possible and
a motor equipped with an encoder is required.
Here below are indicated all necessary setting to control asynchronous “multi-
windings” motor by using drives in Master/Slave conguration. The function is
managed via Fast Link communication (requires EXP-FL-XCAN-ADV card).
The Master drive sends to the Slave drive the three control variables (PAR 220
Theta mon, PAR 224 Flux ref mon, and PAR 2388 Torque ref nolter) needed
to command the function.
Below conguration is required for the MASTER drive:
> REFERENCES menu
PAR 222 Theta ref src set to “Theta ref mon” (default)
PAR 226 Flux ref src set to “Flux ref mon” (default)
> COMMUNICATION/FAST LINK menu
PAR 5730 FL Fwd 1 src set to “Theta ref mon”
PAR 5732 FL Fwd 2 src set to “Flux ref mon”
PAR 5734 FL Fwd 3 src set to “Torque ref nolter”
> FUNCTIONS/CONTROL MODE menu
PAR 6208 Ctrl mode mon set to “Ramp”
Save the setting, switch the drive off and on again to make the enabling effective.
Below conguration is required for the SLAVE drive:
> REFERENCES menu
PAR 222 Theta ref src set to “FL Fwd 1 mon”
PAR 226 Flux ref src set to “FL Fwd 2 mon”
> TORQUE CONFIG menu
PAR 2382 Torque ref 1 src set to “FL Fwd 3 mon”
> FUNCTIONS/CONTROL MODE menu
PAR 6208 Ctrl mode mon set to “Torque”.
Save the setting, switch the drive off and on again to make the enabling effective.
