gefran ADV200 Series User Manual

120 ADV200 • Quick start up guide
below:
D7..D4 D3 D2 D1 D0
Value 0xA 0x0
For each D0, D1, D2, D3 value other than 0x0 search for the sub-values it can be
divided into in table 1.
D0 D1 D2 D3
0x0 0x0 0x0 0x0 0x0
0x1 0x0 0x0 0x0 0x1
0x2 0x0 0x0 0x2 0x0
0x3 0x0 0x0 0x2 0x1
0x4 0x0 0x4 0x0 0x0
0x5 0x0 0x4 0x0 0x1
0x6 0x0 0x4 0x2 0x0
0x7 0x0 0x4 0x2 0x1
0x8 0x8 0x0 0x0 0x0
0x9 0x8 0x0 0x0 0x1
0xA 0x8 0x0 0x2 0x0
0xB 0x8 0x0 0x2 0x1
0xC 0x8 0x4 0x0 0x0
0xD 0x8 0x4 0x0 0x1
0xE 0x8 0x4 0x2 0x0
0xF 0x8 0x4 0x2 0x1
For each D0, D1, D2, D3 value other than 0x0 search for the sub-values it can be
divided into in table 1.
In the table regarding the type of encoder in use, search for the sub-values
obtained from each D0, D1, D2, D3 digit in the corresponding columns Value.D0,
Value.D1, Value.D2, Value.D3
Value.D1 = 2H
Cause: (CRC_CKS_P)disturbed SSI signals cause a CKS error or Parity.
Value.D1 = 8H
Cause: (DT1_ERR) Encoder has detected a malfunction and signals this to the dri-
ve via Error bit. Bits 16..31 contain the type of malfunction detected by the encoder.
● Speed fbk loss [22] alarm with digital incremental encoder
Bit
Value
Name
Description
D7..D4 D3 D2 D1 D0
0 0x1 CHA Cause: no impulses or disturbance on incremental channel A.
Solution: Check the connection of the encoder-drive channel A,
check the connection of the screen, check the encoder supply
voltage.
Check parameters 2102 Encoder 1 supply and 2104 Encoder 1
input cfg (if encoder 1 is used).
Check parameters 5102 Encoder 2 supply and 5104 Encoder 2
input cfg (if encoder 2 is used).
1 0x2 CHB Cause: no impulses or disturbance on incremental channel B.
