gefran ADV200 Series User Manual

ADV200 • Quick start up guide 121
Bit
Value
Name
Description
D7..D4 D3 D2 D1 D0
Solution: Check the connection of the encoder-drive channel B,
check the connection of the screen, check the Encoder 1 supply
voltage.
Check parameters 2102 Encoder 1 supply and 2104 Encoder 1
input cfg (if encoder 1 is used).
Check parameters 5102 Encoder 2 supply and 5104 Encoder 2
input cfg (if encoder 2 is used).
2 0x4 CHZ Cause: no impulses or disturbance on incremental channel Z.
Solution: Check the connection of the encoder-drive channel Z,
check the connection of the screen, check the Encoder 1 supply
voltage.
Check parameters 2102 Encoder 1 supply and 2104 Encoder 1
input cfg (if encoder 1 is used).
Check parameters 5102 Encoder 2 supply and 5104 Encoder 2
input cfg (if encoder 2 is used).
● Speed fbk loss [22] alarm with sinusoidal incremental encoder
Bit
Value
Name
Description
D7..D4 D3 D2 D1 D0
3 0x8 MOD_INCR
Cause: voltage level not correct or disturbance on signals of incre-
mental channels A-B.
Solution: Check the connection of the encoder-drive channels A-B,
check the connection of the screen, check the encoder supply
voltage, check parameter 2102 Encoder 1 supply, check parameter
2108 Encoder 1 signal Vpp.
● Speed fbk loss [22] alarm with SinCos encoder
Bit
Value
Name
Description
D7..D4 D3 D2 D1 D0
3 0x8 MOD_INCR
Cause: voltage level not correct or disturbance on signals of incre-
mental channels A-B.
Solution: Check the connection of the the encoder-drive channels
A-B, check the connection of the screen, check the encoder supply
voltage, check parameter 2102 Encoder 1 supply, check parameter
2108 Encoder 1 signal Vpp.
4 0x1 0x0 MOD_ABS
Cause: voltage level not correct or disturbance on signals of absolute
SinCos channels.
Solution: Check the connection of the the encoder-drive channels
A-B, check the connection of the screen, check the encoder supply
voltage, check parameter 2102 Encoder 1 supply, check parameter
2108 Encoder 1 signal Vpp.
● Speed fbk loss [22] alarm with SSI absolute encoder
Bit
Value
Name
Description
D7..D4 D3 D2 D1 D0
3 0x8 MOD_INCR
Cause: voltage level not correct or disturbance on signals of incre-
mental channels A-B.
