gefran ADV200 Series User Manual

160 ADV200 • Quick start up guide
The ADV200 drive can be used with general purpose standard motors or with
motors specially designed for drive use. The latter usually have a higher isolation
rating to better withstand PWM voltage.
Examples of reference regulations are provided below:
Motors designed for use with Adjustable Frequency Drives do not require any spe-
cic ltering of the voltage waveform from the drive. For general purpose motors,
especially with long cable runs (typically over 100 m [328 feet]) an output choke is
recommended to mantain the voltage waveform within the specied limits.
The rated current of the chokes should be approx. 20% above the rated current
of the frequency drive in order to take into account additional losses due to PWM
waveform.
Sizes 1007 ... 73551
Sizes
Inverter
output
Mains
inductance (mH)
Rated
current (A)
Saturation
current (A)
Type Code
Dimensions (W x H x d,
mm) and Weights
1007 ... 1040
HD 1.4 9.5 20 LU3-003 S7FG2
180 x 170 x 110 - 6.8 kgLD 0.87 16 34 LU3-005 S7FG3
2055
HD 0.87 16 34 LU3-005 S7FG3
LD 0.51 27 57 LU3-011 S7FG4
180 x 185 x 130 - 8 kg
2075 - 2110
HD 0.51 27 57 LU3-011 S7FG4
LD 0.43 32 68 LU3-015 S7FH2
180 x 185 x 140 - 7 kg
3150
HD 0.43 32 68 LU3-015 S7FH2
LD 0.33 42 72 LU3-022 S7FH3
180 x 185 x 160 - 8.2 kg
3185
HD 0.33 42 72 LU3-022 S7FH3
LD 0.23 58 100 LU3-030 S7FH4
180 x 185 x 170 - 10 kg
3220
HD 0.23 58 100 LU3-030 S7FH4
LD 0.24 58 100 LU3-030 S7FH4
4300
HD 0.24 58 100 LU3-030 S7FH4
LD 0.18 76 130 LU3-037 S7FH5
4370
HD 0.18 76 130 LU3-037 S7FH5
LD 0.12 120 205 LU3-055 S7FH6 240 x 216 x 170 - 16 kg
4450
HD 0.12 120 205 LU3-090 S7F10
180 x 165 x 195 - 15 kg
LD 0.07 180 310 LU3-090 S7F10
5550 - 5750 HD / LD 0.07 180 310 LU3-090 S7F10
5900
HD 0.07 180 310 LU3-090 S7F10
LD 0.041 310 540 LU3-160 S7FH8
300 x 265 x 220 - 30 kg61100 - 61320 HD / LD 0.041 310 540 LU3-160 S7FH8
71600
HD 0.041 310 540 LU3-160 S7FH8
LD 0.03 400 770 LU3-200 S7AF0
300 x 270 x 230 - 33 kg
72000
HD 0.03 400 770 LU3-200 S7AF0
LD 0.022 580 1100 LU3-315 S7FH9
370 x 400 x 210 - 65 kg72500 HD / LD 0.022 580 1100 LU3-315 S7FH9
73150
HD
0.022 580 1100 LU3-315 S7FH9
73150
LD
0.015 730 1240 LU3-400 S7FO8
390 x 430 x 270 - 73 kg
73551 HD / LD 0.015 730 1240 LU3-400 S7FO8
Note ! When the drive is operated at the rated current and at 50 Hz, the output chokes cause a voltage drop
of approx. 2% of the output voltage.
