50 ADV200 • Quick start up guide
• mains frequency out of range ( > ±5%). This condition occurs only during the
power-on phase.
• presence of Enable command at terminal 23.
Digital Out 2 – Mains Loss (factory setting)
Digital output 2 connected to terminal 36 goes high at Power On and goes low
under one of the following conditions.
• power failure;
• lack of a power supply phase.
5.2.5.3 R-PSM card conguration switches
The jumpers and switches on these cards are factory-set. If the module is used
according to its standard power supply characteristics the settings should
not be changed.
The R-PSM card has three 4-position conguration switches.
The following tables show all of the permitted combinations.
Legenda:
0 OPEN
1 CLOSE
(*) Default setting for models ADV200-...-4,
(**) Default setting for models ADV200-...-6
Setting for ADV200 drive starting from rmware 7.X.6 and higher (R-PSM
card starting from hardware revision “F”)
S1 - Mains voltage configuration switches
Mains voltage
DC undervoltage trip
threshold
DC undervoltage
return threshold
S1-1 S1-2 S1-3 S1-4
[Vac] [Vdc] [Vdc]
380 330 370 1 0 0 0
400 (*) 330 370 0 1 0 0
415 361 401 1 1 0 0
440 383 423 0 0 1 0
460 400 440 1 0 1 0
480 417 457 0 1 1 0
500 435 475 1 1 1 0
575 500 540 0 0 0 1
690 (**) 600 640 1 0 0 1
