ADV200 • Quick start up guide 51
Setting for ADV200 drive up to rmware 7.X.3
S1 - Mains voltage configuration switches
Mains voltage
DC undervoltage trip
threshold
DC undervoltage
return threshold
S1-1 S1-2 S1-3 S1-4
[Vac] [Vdc] [Vdc]
380 372 412 1 0 0 0
400 (*) 392 432 0 1 0 0
415 407 447 1 1 0 0
440 431 471 0 0 1 0
460 451 491 1 0 1 0
480 470 510 0 1 1 0
500 490 530 1 1 1 0
575 563 603 0 0 0 1
690 (**) 676 716 1 0 0 1
The correct selection of mains voltage is very important for correct setting of
UNDERVOLTAGE limits.
The same value set has to be carried out on PAR560 (DRIVE CONFIG MENU).
S2 - Mains frequency configuration switch
Mains frequency
S2-1
[Hz]
50 (*)
0
60 (**) 1
An incorrect mains frequency setting will disable the control card: the mains fre-
quency tolerance is ±5%.
S2 – Switch configuration for pre-charge times
Selection of pre-charge time
for 50Hz
Selection of pre-charge time
for 60Hz
S2-2 S2-3 S2-4
[s] [s]
17.4 24.1 0 0 0
11.6 (*)(**) 12.1 1 0 0
8.7 8 0 1 0
6.9 6 1 1 0
5.0 4.8 0 0 1
3.5 3.4 1 0 1
2.7 2.7 0 1 1
1.9 2 1 1 1
Switch S2-2…4 lets you set the pre-charge time for the capacitors connected to
the DC link.
The default conguration calls for a time of 11.6[s] for a 50[Hz] line and 12.1[s] for
a 60[Hz] line.
Remember that with equal levels of energy to be transferred to the condenser
bank, decreasing the precharge time increases the current draw.
The rectier bridge and pre-charge inductance are sized for maximum peak cur-
rent of 400[Apk].
