ADV200 • Quick start up guide 83
Note ! At the end of the self-tuning procedure there is a request to open the Enable contact (terminals
7 – S3); the Take tune parameters command (menu 16 MOTOR DATA, PAR: 2078) is automatically
executed.
The calculated parameters are saved in a RAM memory to enable the drive to perform the neces-
sary calculations. These data are lost if the device is switched off. To save the motor data follow the
procedure described in Step 6.
When the Enable contact is opened the drive proposes Step 4 to proceed with the
wizard
Step 3B - Self-tuning with motor at stand-still or coupled to the load
(Autotune still)
Use this procedure when the motor is coupled to the transmission and cannot
rotate freely.
May cause limited rotation of the shaft.
Peut entraîner une rotation de l’arbre limitée.
Note ! Autotuning can be cancelled at any time by pressing
T+ T- EN LO C ILim n:0 AL
STARTUP WIZARD
Run autotune still ?
E=Yes Down=Next
E
T+ T- EN LO C ILim n:0 AL
STARTUP WIZARD
Close Enable input
Esc=Abort
T+ T- EN LO C ILim n:0 AL
Autotune still
SEQ.01
PA R: 2024
PressEto execute
T+ T- EN LO C ILim n:0 AL
Autotune
Press Esc to abort
Progress 5%
T+ T- EN LO C ILim n:0 AL
STARTUPWIZARD
Open Enable input
Connect terminal 7 (Enable) to terminal S3 (+24V
dc
)
Note ! At the end of the self-tuning procedure there is a request to open the Enable contact (terminals
7 – S3); the Take tune parameters command (menu 16 MOTOR DATA, PAR: 2078) is automatically
executed.
The calculated parameters are saved in a RAM memory to enable the drive to perform the neces-
sary calculations. These data are lost if the device is switched off. To save the motor data follow the
procedure described in Step 6.
When the Enable contact is opened the drive proposes Step 4 to proceed with the
wizard.
Caution
