Final check
Note!
If you wish to use the inertia value calculated by the converter, you should copy the parameter value 5.4.20 CalcInertia (PAR 12020, Menu LIFT/ MECHANI-
CAL INFORMATION) in parameter 16.20 Inertia, PAR: 2240.
Menu 5.4 MECHANICAL DATA, parameter 5.4.20 CalcInertia, PAR: 12020, default=(S).
01 MONITOR
02 DRIVE INFO
03 STARTUP WIZARD
04 DRIVE CONFIG
05 LIFT

x3
5.1 SPEED
5.2 RAMPS
5.3 LIFT SEQUENCES
5.4 MECHANICAL DATA
5.5 DISTANCE

5.4
MECHANICAL DATA
12/12 PAR: 12020
CalcInertia
4.11 kgm
2
Menu 16 SPEED REG GAINS, parameter 16.20 Inertia, PAR: 2240, default=(S).
14 MOTOR DATA
15 ENCODER CONFIG
16 SPEED REG GAINS
17 REGULATOR PARAM
18 TORQUE CONFIG

x2
16
SPEED REG GAINS
20/21 PAR: 2240
Inertia
4.11 kgm
2
Def: 4.110
Check parameter settings before starting the motor and change if necessary.
Menu 21 ALARM CONFIG, parameter 21.12 Overspeed threshold, PAR: 4540.
17 REGULATOR PARAM
18 TORQUE CONFIG
19 FUNCTIONS
20 COMMUNICATION
21 ALARM CONFIG

x11
21
ALARM CONFIG
12/50 PAR: 4540
Overspeed threshold
144 rpm
