ADL300 • Quick installation guide - Specifications and connection 9
Independent conguration of acceleration and deceleration ramp parameters and of the 4 jerk values for maximum
travelling comfort in the lift cabin. Two independent S-shaped ramps, selectable via digital input with 4 independent jerk
settings. Dedicated deceleration ramp corresponding to the stop command.
Multiple speeds
8 internally settable speed reference values. Possibility of overwriting at start-up with additional values to ensure
smooth starting.
Pre-torque (load compensation)
Initialisation of the speed regulator by the weight sensor to prevent jerks or bumpy starting.
Increased overload
Overload capacity in line with typical lift application load cycles.
Fan control logic
The fan control logic activates the internal fans according to the temperature.
Emergency single-phase power supply to return to the oor
In emergency conditions a 230 V single-phase supply voltage can be used to return the cabin to the oor (by UPS
power supply or batteries with EMS module).
User-friendly menus
The menus feature lift-specic DISPLAY and motor STARTUP terminology
Saving parameters
Drive parameters can be saved on the keypad (5 settings) or on a Secure Digital memory card.
Fieldbus
The drive supports remote control via the CANopen (DS417) or DCP3/DCP4 protocol.
Management of synchronous and asynchronous motors
The operating mode is selectable via parameter.
Integrated encoder management
5 V TTL / 24V HTL incremental digital encoder
(models ADL300A-...) or absolute SinCos, EnDat-SSi and Hiperface (mod-
els ADL300A-...) feedback selectable via parameter.
2.2 Other features
Autotuning of motor parameters and automatic phasing for brushless motors.
SSC (Sensorless Scalar Control) modulation reduces noise levels to a minimum.
Switching frequency xed at 10 kHz.
Output voltage up to 98% of input voltage.
Saving of messages relating to the last 30 repairs and indication of time of repair.
Drive, motor and braking unit overload protection.
Different digital and analog I/O cards can be selected to adapt the drive to the system (models ADL300A-...).
Speed regulator adaptive.
Readout of speed functions.
Easy use of the equipment via:
- terminal strip
- Integrated LED keypad
- optional keypad, simple and immediate to use, with magnetic fastening and remote control at distances of up to 15 m.
- integrated RS232 serial communication with Modbus RTU protocol
The output is protected against accidental grounding and output phase short circuit
Speed regulator powered by switched-mode power supply from DC bus.
Mains dip protection.
Galvanic isolation between power and regulation sections.
