72 ADL300 • Quick installation guide - Specifications and connection
8.2.6 Displaying and resetting Alarms
Note !
The alarms are shown on the display of the integrated keypad with the abbreviated text shown in brackets "[XXX]" in chapter "10.1 Alarms" on page 88 .
Active alarms are displayed by a ashing indicator.
Alarms that have been removed but not yet reset are xed.
If there is more than one alarm, these can be displayed using the up and down arrow keys.
Press Prg to exit the alarm display mode.
To reset an alarm, press the up and down arrow keys together.
To display the sub-codes, press Enter:
E.g.:
PL CE
Enter
00.01.
Prg
Index Error message shown on
the display [on the inte-
grated keypad]
Sub-code Description
47 Error config plc [PLCE]
Condition: may occur during loading of the Mdplc application
The Mdplc application present on the drive is not run.
0004H-4 The application downloaded has a different Crc on DataBlock and Function table
8.2.6.1 Alarm Log
Enter menu 22 - ALARM LOG to display the list of alarms
Use the arrow keys to scroll the list with the abbreviations shown in chapter 10.1.
Press Enter to display the alarm code.
8.2.7 Startup wizard
Enter Menu 3 - STARTUP WIZARD to scroll the list of operations, which are abbreviated as follows:
Operations displayed on the optional keypad Operations displayed on the integrated keypad
Set motor data? MOT
Run autotune still? STIL
Set encoder param? ENC
Set max motor speed? MSPD
Set max car speed? CSPD
Set system weights? WEIG
Set application par? LIFT
Save parameters? SAVE
End of sequence! END
Press Enter to enter the selected operation.
At this point, the list of associated parameters that must be modied as described previously is displayed.
Motor self-tuning is described below.
Press the down arrow to move on to the next operation.
Press the up arrow to return to the previous operation.
Press Prg to abort the STARTUP WIZARD sequence.
Note ! The STARTUP WIZARD cannot run simultaneously on the two keypads (integrated and optional).
When running on one, it cannot be accessed from the other.
Note ! For further information see chapters "9.1 Asynchronous motor startup wizard" on page 81 and "9.2 Startup wizard for brushless motors on page 93 .
