68 ADL300 • Quick installation guide - Specifications and connection
8.2 Navigating with the integrated keypad
8.2.1 Scanning of rst and second level menus
First level
01.88.

23.88.

02.88.
First level menus are shown by 2 digits.
First level Second level
05.88.
Enter
05.01.
Second level menus are shown by 4 digits separated by a point.
The rst two indicate the rst level, the second two the second level.
The numbering of the menus is that displayed on the standard keypad.
Use the up and down arrow keys to scroll the menu.
Press Enter to open a menu item.
Press Prg to go bac.
Note ! This example is only visible in Expert mode.
8.2.2 Display
• List of parameters (IPA)
01.88.
Enter
82.50.

14. 00.
Enter
00.0.1.
Prg
14. 00.
Prg
01.88.
01.88.
Enter
82.50.

82.52.
Enter
88. 5.4
Prg
82.52.
Prg
01.88.
When you access a list of parameters from the menu, the rst value to be displayed is the parameter's IPA.
Scroll the list using the arrow keys.
Press Enter to display the value of the parameter.
Press Prg to return to the menu.
Only 4 characters are displayed, which means it is not possible to distinguish between regulation parameters and
application parameters. Application parameters are only in menu 5. In this menu the rst character on the left is not
displayed, e.g.: for PAR 11002 Travel units sel, "1002" is displayed.
• Display using "windows”
With the optional keypad, numbers of up to 10 digits plus the sign can be displayed.
With the integrated keypad only 4 digits plus the sign are displayed.
The four digits are considered as a window on the complete number, which can alternately display the four least signi-
cant digits, the four intermediate digits or the 2 most signicant digits.
The active window is always shown by a ashing point, in a different position:
> Bottom window: indicated by the ashing point of the second digit from the right:
Top Middle Bottom
Window >>> 7 8 9. 0
Complete number >>> 1 2 3 4 5 6 7 8 9 0
> Middle window: indicated by the ashing point of the second digit from the left:
Top Middle Bottom
Window >>> 3 4. 5 6
Complete number >>> 1 2 3 4 5 6 7 8 9 0
> Top window: indicated by the ashing point of the rst digit from the left:
Top Middle Bottom
Window >>> 1. 2
Complete number >>> 1 2 3 4 5 6 7 8 9 0
