88 ADL300 • Quick installation guide - Specifications and connection
9.1 Asynchronous motor startup wizard (with the optional keypad)
The ADL300 can operate with regulation modes: Voltage/Frequency (SSC) , Sensorless (open loop) and eld-oriented
vector control (closed loop).
Note! Before starting, check the factory settings:
Menu 02 DRIVE INFO, parameter 02.2 Control type, PAR: 480, default=11.
01 MONITOR
02 DRIVE INFO
03 STARTUP WIZARD
04 DRIVE CONFIG
05 LIFT

02 DRIVE INFO
2/26 PAR: 480
Control type
Asynchronous
Value: 11
Menu 04 DRIVE CONFIG, parameter 04.2 Regulation mode, PAR: 552, default=SSC control.
01 MONITOR
02 DRIVE INFO
03 STARTUP WIZARD
04 DRIVE CONFIG
05 LIFT
 
x1
04 DRIVE CONFIG
2/19 PAR: 552
Regulation mode
SSC control
Value: 0
The STARTUP WIZARD is a guided procedure used for quick start-up of the drive that helps to set the main
parameters.
It consists of a series of questions, relating to the various sequences for entering and calculating the parameters
necessary for correct drive and lift application operation. The order of these sequences is as follows:
● Electrical connections See step 1
● Setting motor parameters See step 2
● Autotune with motor at stand-still or coupled to the load See step 3
● Setting encoder parameters (with control mode=Flux vector CL) See step 4
● Setting the maximum speed reference and maximum system speed See step 6
● Setting system weights See step 7
● Setting application parameters See step 8
● Saving parameters See step 9
The format of the function selection page is as follows:
01 MONITOR
02 DRIVE INFO
03 STARTUP WIZARD
04 DRIVE CONFIG
05 LIFT

03 STARTUP WIZARD
Set motor data?
E=Yes Down=Next
Pressing the E key, the function to be programmed is accessed.
Press the ▼ (Down) key to move to the next function skipping the current function.
Press the ▲ (Up) key to return to the previous function.
To terminate the sequence of functions and return to the menu, press the ESC key.
The end of the start-up sequence is indicated with the page:
03 STARTUP WIZARD
End of se
q
uence!
Up=Back Down=Exit
Press the ▼(Down) key to exit the sequence and return to the menu.
