ADL300 • Quick installation guide - Specifications and connection 39
7.1.5 Internal EMC lter (standard)
The ADL300.-...-F-.. series of inverters are equipped with an internal EMI lter (optional for the ADL300-...-2M series)
able to guarantee the performance levels required by EN 12015, rst environment, with max 10 m of shielded motor
cable.
Compliance with these requirements means the drive can be incorporated into lift systems built to EN 12015.
7.1.6 Power line connection
L1 L2 L3 BR C1 CDUVWEM
K1M
L1 L2 L3
F1
(0 V/ 400 50/60 Hz)
AC3ph - 23 V/ 460-480 VAC AC,
L1 L2 L3 BR1 CDUVW EM
K1M
L1 L2 L3
F1
(0 V/ 400 50/60 Hz)
AC3ph - 23 V/ 460-480 VAC AC,
BR2
L1 L2 L3 CDUVW EM
K1M
L1 L2 L3
F1
(0 V/ 400 50/60 Hz)
AC3ph - 23 V/ 460-480 VAC AC,
L1 L2 BR C1 CDUVWEM
K1M
F1
(0 V/ 230 50/60 Hz)AC1ph - 20 VAC,
ADL.-
ADL.-5370-2T
5750-4
ADL.-1011...3055-2M
ADL.-1040...3220-4
ADL.-2055...3110-2T
ADL.- -44300...5550
ADL.- -2T4150...5300
Note! Recommended combination F1 fuses: see paragraph 5.1.1.
7.1.7 Connection of AC and DC chokes (optional)
(For three-phase ADL300 only). The drive can use both a three-phase choke on the AC power line and, for 4 to 22 kW
drives only, a DC choke between terminals C1 and C. Refer to chapter 5.2 for the recommended connections.
If no DC choke is used on 4 to 22 kW drives, terminals C1 and C must be bridged.
If no DC choke is used, terminals C1 and C must be bridged (sizes 1-2 e 3).
