20 ADL300 • Quick installation guide - Specifications and connection
4.6
Voltage level of the inverter for safe operations
The minimum time between the moment in which an ADL inverter is disabled from the mains and that in which an
operator can operate on internal parts of the inverter, without the danger of electric shock, is 5 minutes.
This value takes into account the time to turn off an inverter supplied at 460 Vac + 10%, without any options (time indicated for disabled
inverter condition).
4.7
No-load consumption (Energy rating)
Size No. of pre-loads allowed Power-on
time
[secs]
Stand-by consumption
"Fan Off"
[W]
Fan consumption
[W]
Stand-by consumption
"Fan On"
[W]
ADL300-...-4, 3ph
1040 1 each 20 sec. 5 abt. 20 4 24
1055 1 each 20 sec. 5 abt. 20 10 30
2075 1 each 20 sec. 5 abt. 20 10 30
2110 1 each 20 sec. 5 abt. 20 8 28
3150 1 each 20 sec. 5 abt. 20 16 36
3185 1 each 20 sec. 5 abt. 20 15 35
3220 1 each 20 sec. 5 abt. 20 15 35
4300 1 each 20 sec. 5 abt. 25 25 45
4370 1 each 20 sec. 5 abt. 25 36 56
4450 1 each 20 sec. 5 abt. 25 36 56
5550 1 each 20 sec. 5 abt. 25 34 59
5750 1 each 20 sec. 5 abt. 25 72 97
ADL300-...-2T, 3ph
2055
1 each 20 sec. 5 abt. 20 8 28
3075
1 each 20 sec. 5 abt. 20 16 36
3110
1 each 20 sec. 5 abt. 20 15 35
4150
1 each 20 sec. 5 abt. 25 25 45
4185
1 each 20 sec. 5 abt. 25 36 56
4220
1 each 20 sec. 5 abt. 25 36 56
5300
1 each 20 sec. 5 abt. 25 34 59
5370
1 each 20 sec. 5 abt. 25 72 97
ADL300-...-2M, 1ph
1011 1 each 20 sec. 5 abt. 20 4 24
1015 1 each 20 sec. 5 abt. 20 10 30
2022 1 each 20 sec. 5 abt. 20 10 30
2030 1 each 20 sec. 5 abt. 20 8 28
3040 1 each 20 sec. 5 abt. 20 16 36
3055 1 each 20 sec. 5 abt. 20 15 35
