28 ADL300 • Quick installation guide - Specifications and connection
5.4 External braking resistors (optional)
Recommended combinations for use with internal braking unit.
Table 5.4.1: Recommended combination ADL...-AC and ADL...-BR series
Size
List and technical data of standard external resistors
Resistor type Code Q.ty
Max. overload, 1"
- service 10%
E
br (kJ)
Max. overload, 30"
- service 25%
Ebr (kJ)
Pnbr
(W)
Rbr
(Ω)
Housing
Dimensions:
Width x Height x
Depth (mm)
Weight
(kg)
ADL300-...-4, 3ph
1040 RFPD 750 DT 100R S8SY4 1 7.5 38 750 100 IP44 200 x 70 x 106 1.7
1055 RFPR 750 D 68R S8SZ3 1 7.5 38 750 68 IP44 245 x 75 x 100 2.7
2075 RFPR 750 D 68R S8SZ3 1 7.5 28 750 68 IP44 245 x 75 x 100 2.7
2110 RFPR 1200 D 49R S8SZ4 1 7.5 28 1200 49 IP44 310 x 75 x 100 4.2
3150 RFPR 1900 D 28R S8SZ5 1 12 43 1500 28 IP44 365 x 75 x 100 4.2
3185 BRT4K0-15R4 S8T00G 1 40 150 4000 15.4 IP20 625 x 100 x 250 7.0
3220 BRT4K0-15R4 S8T00G 1 40 150 4000 15.4 IP20 625 x 100 x 250 7.0
4300 BRT4K0-11R6 S8T00H 1 40 150 4000 11.6 IP20 625 x 100 x 250 7.0
4370 BRT4K0-11R6 S8T00H 1 40 150 4000 11.6 IP20 625 x 100 x 250 7.0
4450 BRT8K0-7R7 S8T00I 1 40 150 8000 7.7 IP20 625 x 165 x 250 10.0
5550 BRT8K0-7R7 S8T00I 1 40 150 8000 7,7 IP20 625 x 165 x 250 10.0
5750 External braking unit (BUy series, optional)
ADL300-...-2T, 3ph
2055 RFPR 1200 D 49R S8SZ4 1 12 43 1200 49 IP44 310 x 75 x 100 4.2
3075 RFPR 1900 D 28R S8SZ5 1 19 75 1500 28 IP44 365 x 75 x 100 4.2
3110 BRT4K0-15R4 S8T00G 1 40 150 4000 15.4 IP20 625 x 100 x 250 7.0
4150 BRT4K0-11R6 S8T00H 1 40 150 4000 11.6 IP20 625 x 100 x 250 7.0
4185 BRT4K0-11R6 S8T00H 1 40 150 4000 11.6 IP20 625 x 100 x 250 7.0
4220 BRT8K0-7R7 S8T00I 1 40 150 8000 7.7 IP20 625 x 165 x 250 10.0
5300 BRT8K0-7R7 S8T00I 1 40 150 8000 7.7 IP20 625 x 165 x 250 10.0
5370 External braking unit (BUy series, optional)
ADL300-...-2M, 1ph
1011 RF 220 T 100R S8T0CE 1 1.5 11 200 100 IP44 300 x 27 x 36 0.5
1015 RF 220 T 68R S8T00T 1 1.5 11 200 68 IP44 300 x 27 x 36 -
2022 RF 300 D 34R S8T0CH 1 2.5 24 300 34 IP44 260 x 38 x 106 1.4
2030 RF 300 D 34R S8T0CH 1 2.5 24 300 34 IP44 260 x 38 x 106 1.4
3040 RFPD 750 DT 26R S8T0CZ 1 4.5 43 750 26 IP44 200 x 70 x 106 1.7
3055 RFPD 750 DT 26R S8T0CZ 1 4.5 43 750 26 IP44 200 x 70 x 106 1.7
Pnbr Braking resistor rated power
Rbr Braking resistor ohmic value
Ebr Maximum energy that can be dissipated on the resistor
Braking resistors may be subject to unexpected overloads due to faults.
Resistors MUST be protected using thermal cutouts. These devices must not interrupt the circuit in which the resistor is
inserted but their auxiliary contact must cut off the power supply to the power section of the drive. If the resistor requires a
protection contact, this must be used together with that of the thermal cutout.
A la suite de pannes, les résistances de freinage peuvent être sujettes à des surcharges imprévues. La protection des résist
-
ances au moyen de dispositifs de protection thermique est absolument capitale. Ces dispositifs ne doivent pas interrompre le
circuit qui abrite la résistance, mais leur contact auxiliaire doit couper l’alimentation du côté puissance du drive. Si la résist
-
ance prévoit un contact de protection, ce dernier doit être utilisé conjointement à celui du dispositif de protection thermique.
