gefran installationSIEIDrive ADL300 User Manual

40 ADL300 • Quick installation guide - Specifications and connection
7.1.8 Motor connection
L1 L2 L3 BR C1 CDUVWEM
M
3 ph
K3MK2M
L1 L2 L3 BR1 BR2 CDUVW EM
M
3 ph
K3MK2M
L1 L2 L3 CDUVW EM
M
3 ph
K3MK2M
L1 L2 BR C1 CDUVWEM
M
3 ph
K3MK2M
ADL.-
ADL.-5370-2T
5750-4
ADL.-1011...3055-2M
ADL.-1040...3220-4
ADL.-2055...3110-2T
ADL.- -44300...5550
ADL.- -2T4150...5300
7.1.9 Connection of braking resistor (optional)
L1 L2 L3 BR C1 CDUVWEM
Braking resistor
L1 L2 L3 BR1 BR2 CDUVW EM
Braking resistor
L1 L2 BR C1 CDUVWEM
Braking resistor
ADL.-1011...3055-2M
ADL.-1040...3220-4
ADL.-2055...3110-2T
ADL.- -44300...5550
ADL.- -2T4150...5300
Note! Recommended combination braking resistors: see paragraph 5.4.
For sizes 5750 and 5370 an optional external BUy braking unit can be used and connected to terminals Cand D. Refer to the BUy handbook for further information.
