8 ADL300 • Quick installation guide - Specifications and connection
2 - Introduction to the product
The SIEIDrive ADL300 is the result of GEFRAN’s experience in the civil lift engineering sector, gained from its
commitment to working in close partnership with leading operators in the sector to develop technical solutions and
application programs.
The ADL300 integrates the most complete and advanced lift inverter technology, for maximum synergy with the full
range of installation requirements but, above all, to offer a cost-effective and immediate solution for lift control systems.
This drive is designed to power loads such as asynchronous or synchronous permanent magnet (brushless) motors,
for applications in the lift sector.
This compact drive is suitable for installation in cabinets for roomless applications.
The ADL300 is available in two congurations:
• ADL300 Basic
Designed and produced to meet the full range of requirements in the lift sector, the ADL300 Basic features the following
as standard:
• 8 programmable digital inputs (NPN/PNP) + an Enable input
• 4 single-contact programmable relay outputs
• Input for 5 Vdc TTL incremental digital encoder
• Input for absolute SinCos or Endat / SSI encoder
• Single output contactor: The ADL300 is certied for the use of a single output contactor, in accordance with
UNI EN 81-1:1998 + A3, EN81-20, EN81-50.
• Safety Certication for a CONTACTORLESS operations: ADL300 is CERTIFIED as EN81-1:1998 + A3, EN81-
20, EN81-50; SIL3 according to EN61800-5-2:2007.
• Integrated LED keypad
• Integrated EMI lter (models ADL300B-...-F)
• SD card for storing/copying parameters.
• ADL300 Advanced
To guarantee maximum programmability, the ADL300 Advanced is supplied as standard with no I/O or feedback cards,
leaving the customer free to perform the appropriate conguration, choosing from an extensive range of options. The
standard conguration consists of:
• Single output contactor: The ADL300 is certied for the use of a single output contactor, in accordance with
UNI EN 81-1:1998 + A3, EN81-20, EN81-50.
• Safety Certication for a CONTACTORLESS operations: ADL300 is CERTIFIED as EN81-1:1998 + A3, EN81-
20, EN81-50; SIL3 according to EN61800-5-2:2007.
• Integrated LED keypad
• Integrated EMI lter (models ADL300A-...-F)
• SD card for storing/copying parameters.
2.1 Dedicated features
The ADL300 incorporates basic and advanced lift functions in a single product, to ensure maximum comfort for all
systems at all times.
• Speed control
EFC (Elevator Floor Control) function: separate function for independent management of short oors, landing zone,
re-starting with lift not at oor and automatic deceleration point calculation.
• Position control
EPC (Elevator Positioning Control) function: separate function for independent management of direct arrival at the oor
with internal position regulator and saving of oor distances (system autotuning).
• Lift sequence
Typical sequence of input/output signals used in civil lift engineering applications such as I/O management, braking,
output contactor and door control.
• Parameters in linear unit
Possibility of selecting different engineering units (also with values for the US) for the main movement parameters, rpm
(fpm) or m/s for speed, m/s², m/s³ (ft/s
2
, ft/s
3
) for cabin acceleration.
• Lift mechanical parameters
Mechanical system parameters such as pulley diameter and speed ratio for converting system units and weights,
system for calculating inertia and speed regulation for the desired response.
• Ramp generation
