44 ADL300 • Quick installation guide - Specifications and connection
(*) Standard = +24V OUT; +24V IN/OUT versions on request;
(**) Cards with +24V external power supply (+24V IN/OUT versions) must be separated from the external power supply with an external diode. Check if the diode is
already present on the external power supply.
Figure 7.2.3: Recommended card wiring
7.2.3 Feedback Connection
This section describes the feedback connections for the ADL300B series.
For the ADL300A series, see section A3 of the Appendix.
Note! All terminal boards are extractable.
Figure 7.2.4: Connection of shielding (recommended)
Note! The indicated connection is not valid for ADL300B-...-AD1: in this model, the shield must be connected to the VGA connector shell.
Technical data and connections for the most common encoder types are shown below.
See the table on page 14 to check which encoders can be connected to your model ADL300B.
