gefran installationSIEIDrive ADL300

22 ADL300 • Quick installation guide - Specifications and connection
4.9 Weights and dimensions
Figure 4.9.1: Size 1 dimensions
162 (6.38)
115 (5.53)23.5 (0.93)
115 (4.53)
148.1 (5.83)
320.2 (12.60)
321.2 (12.64) 7.5 (0.29)
7.5 (0.29)
17
5.5
11.5
9
5.5
11
5.3
135.5 (5.33) 23.6 (0.93)
159 (6.26)
343 (13.50)
383 (15.07)
A
B
C
A
SCALA 2:1
B
SCALA 2:1
C
SCALA 2:1
Sizes
Dimensions: Width x Height x Depth Weight
(mm) (inches) (kg) (lbs)
ADL300.- 1040/1055-...-4
162 x 343 x 159 6.38 x 13.50 x 6,26 5.8 12.8
ADL300.- 1011/1015-...-2M
Figure 4.9.2: Size 2 dimensions
159 (6.26)
162 (6.38)
5.5
11.5
17
9
5.5
5.3
11
148.1 (5.83)
115 (5.53)
23.5 (0.93) 115 (5.53)
7.5
376.2 (14.81)
135.5 (5.33) 23.6 (0.93)
396 (15.59)
437 (17.20)
A
B
C
(3:5)A
(3:5)B
(3:5)C
Sizes
Dimensions: Width x Height x Depth Weight
(mm) (inches) (kg) (lbs)
ADL300.- 2075/2110-...-4
162 x 396 x 159 6.38 x 15.59 x 6.26 7.8 17.2ADL300.- 2055-...-2T
ADL300.- 2022/2030-...-2M
