112 ADL300 • Quick installation guide - Specifications and connection
● Speed fbk loss [22] alarm with EnDat absolute encoder
Bit Value Name Description
3 0x08 MOD_INCR Cause: voltage level not correct or disturbance on signals of incremental channels A-B.
Solution: Check the connection of the the encoder-drive channels A-B, check the connection of the screen, check the encoder supply voltage, check
parameter 2102 Encoder supply, check parameter 2108 Encoder signal Vpp.
5 0x20 CRC_CKS_P Cause: SSI signals not present or disturbed cause an error on CRC
Solution: Check the connection of the clock and encoder-drive data, check the connection of the screen, check the encoder supply voltage, check
parameter 2102 Encoder supply.
8 0x100 Setup error Cause: An error occurred during setup.
Solution: Check the connection of the clock and encoder-drive data, check the connection of the screen, check the encoder supply voltage, check
parameter 2102 Encoder supply.
The following conditions occur while resetting the encoder following Speed fbk loss [22] activation
Bit Value Name Description
6 0x40 ACK_TMO Cause: SSI signals not present or disturbed cause an error on CRC
Solution: Check the connection of the clock and encoder-drive data, check the connection of the screen, check the encoder supply voltage, check
parameter 2102 Encoder supply.
7 0x80 DT1_ERR Cause: Encoder has detected malfunction and signals this to the drive via bit DT1. Bits 16..31 contain the type of malfunction detected by the encoder.
Solution: See the encoder manufacturer's technical guide.
16.31
Bit =0 =1
0 Light source OK Failure (1)
1 Signal amplitude OK Erroneous (1)
2 Position value OK Erroneous (1)
3 Over voltage NO Yes (1)
4 Under voltage NO Under voltage supply (1)
5 Over current NO Yes (1)
6 Battery OK Change the battery (2)
7..15
(1) Can also be set after the power supply is switched off or on.
(2) Only for battery-buffered encoders
● Speed fbk loss [22] alarm with Hiperface absolute encoder
Bit Value Name Description
3 0x08 Cause: voltage level not correct or disturbance on signals of incremental channels A-B.
Solution: Check the connection of the the encoder-drive channels A-B, check the connection of the screen, check the encoder supply voltage, check
parameter 2102 Encoder supply, check parameter 2108 Encoder signal Vpp.
5 0x20 Cause: disturbed SSI signals cause a CKS error or Parity
Solution: Check the connection of the clock and encoder-drive data, check the connection of the screen, check the encoder supply voltage, check
parameter 2102 Encoder supply.
6 0x40 Cause: Encoder does not recognise the command that has been sent to it and replies with ACK. The SSI signals not present cause a TMO error.
Solution: Check the connection of the clock and encoder-drive data, check the connection of the screen, check the encoder supply voltage, check
parameter 2102 Encoder supply.
8 0x100
Cause: An error occurred during setup.
Solution: Check the connection of the clock and encoder-drive data, check the connection of the screen, check the encoder supply voltage, check
parameter 2102 Encoder supply.
The following conditions occur while resetting the encoder following Speed fbk loss [22] activation.
Bit Value Name Description
7 0x80 DT1_ERR Cause: Encoder has detected malfunction and signals this to the drive via Error bit. Bits 16..31 contain the type of malfunction detected by the encoder.
Solution: See the encoder manufacturer's technical guide.
16.31
Type Code Description
Transmission 09h Transmitted parity bit is incorrect
0AH Checksum of transmitted data is wrong
0BH Incorrect command code
To Next Page
