24 ADL300 • Quick installation guide - Specifications and connection
Figure 4.9.5: Size 5 dimensions
305 (12.00)
331.4 (13.05)
311 (12.24)
297 (11.69)
190 (7.48) 30 38.5
25
22
21
14
14
15
8.75
730.4 (28.75)
265 (10.43)
19
6.5
13
8.38
304.8 (12)
767 (30.20)
6.5
A
(3:5)A
1.6
Sizes
Dimensions: Width x Height x Depth Weight
(mm) (inches) (kg) (lbs)
ADL300.- 5550/5750-...-4
311 x 767 x 331.4 12 x 30.2 x 13.05 60 132.3
ADL300.- 5300/5370-...-2T
