General Dynamics R2670 Series - Table 6-6 Trunking Frequency Information Example

107
Example:
The radio service software (RSS) for a UHF
radio system is used to read the system data from
a UHF radio. The following information is
obtained from the radio (Refer to table 6-6):
Table 6-6 Trunking Frequency Information Example
Control Channels (MHz) Channel Ranges Chan Spacing (kHz)
Receive Transmit Start End 25.00
1-408.00000 413.00000 1-Rx 406.02500 409.00000 25.00
2-410.00000 415.00000 1-Tx 406.02500 414.00000 25.00
3-415.00000 420.00000
4-408.50000 413.50000 2-Rx 409.02500 412.02500 25.00
2-Tx 414.02500 417.02500 25.00
3-Rx 412.05000 415.50000 25.00
3-Tx 417.05000 420.50000 25.00
