General Dynamics R2670 Series User Manual

Table 10-7. Astro Signaling Events System Initiated Call Alert Testing Without Auto Affiliation
SIGNALING EVENT DESCRIPTION
F Control Channel Idle The trunking analyzer outputs a background pattern on the control channel to lock
the radio.
M Call Alert Ring OSW The trunking analyzer sends a call alert ring OSW to the target radio.
N Call Alert Ring Ack ISW The radio sends a call alert ring ack ISW to indicate the radio received the call alert.
O Call Alert Ring Ack OSW The trunking analyzer sends call alert ring acknowledge OSW to simulate the
system sending an acknowledge to the requesting radio.
Table 10-8. Astro Signaling Events System Initiated Call Alert Testing With Auto Affiliation
SIGNALING EVENT DESCRIPTION
A Control Channel Idle The trunking analyzer outputs a background pattern on the control channel for the
radio to lock onto.
D Affiliate ISW Received The trunking analyzer received the Affiliate ISW from the radio.
E Affiliate OSW Sent The trunking analyzer sends Affiliate OSWs on the control channel. The Affiliate
OSW acknowledges the radio is registered on the system and tells the radio which
connect tone to use.
F Control Channel Idle The trunking analyzer outputs a background pattern on the control channel to lock
the radio.
M Call Alert Ring OSW The trunking analyzer sends a call alert ring OSW to the target radio.
N Call Alert Ring Ack ISW The radio sends a call alert ring ack ISW to indicate the radio received the call alert.
O Call Alert Ring Ack OSW The trunking analyzer sends call alert ring acknowledge OSW to simulate the
system sending an acknowledge to the requesting radio.
154
