General Dynamics R2670 Series - Table 7-21. Trunk II Signaling Events System Initiated Call Alert Testing Without Auto Affiliation; Table 7-22. Trunk II Signaling Events System Initiated Call Alert Testing with Auto Affiliation

Table 7-21. Trunk II Signaling Events
System Initiated Call Alert Testing Without Auto Affiliation
SIGNALING EVENT DESCRIPTION
F Control Channel Idle
The trunking analyzer outputs a background pattern on the control channel
to lock the radio.
M Call Alert Ring OSW The trunking analyzer sends a call alert ring OSW to the target radio.
N Call Alert Ring Ack ISW
The radio sends a call alert ring ack ISW to indicate the radio received the
call alert.
O Call Alert Ring Ack OSW
The trunking analyzer sends call alert ring acknowledge OSW to simulate
the system sending an acknowledge to the requesting radio.
Table 7-22. Trunk II Signaling Events
System Initiated Call Alert Testing With Auto Affiliation
SIGNALING EVENT DESCRIPTION
A Control Channel Idle
The trunking analyzer outputs a background pattern on the control channel
for the radio to lock onto.
D Affiliate ISW Received The trunking analyzer received the Affiliate ISW from the radio.
E Affiliate OSW Sent
The trunking analyzer sends Affiliate OSWs on the control channel. The
Affiliate OSW acknowledges the radio is registered on the system and tells
the radio which connect tone to use.
F Control Channel Idle
The trunking analyzer outputs a background pattern on the control channel
to lock the radio.
M Call Alert Ring OSW The trunking analyzer sends a call alert ring OSW to the target radio.
N Call Alert Ring Ack ISW
The radio sends a call alert ring ack ISW to indicate that the radio received
the call alert.
O Call Alert Ring Ack OSW
The trunking analyzer sends call alert ring acknowledge OSW to simulate
the system sending an acknowledge to the requesting radio.
131
