REAR PANEL DC INPUT PORT
Drawing shows pins as seen from a rear view of
the Analyzer.
Positive DC voltage must be between +11 and
+18VDC.
Either "+" pin may be used for the positive DC
voltage since these two pins are tied together
internally.
1
2
3
4
+
+
-
Figure D-1. Rear Panel DC Input Port
D-2
