General Dynamics C4 Systems URC-200 (V2)
105
a. Turn the transceiver on and note the input current. It should be approximately 240mA. If
the current exceeds 330mA, a problem exists in the transceiver. Turn off the power and
troubleshoot the transceiver.
b. Set the frequency presets as listed in Table 21 on the URC-200 (V2). For each preset
channel, adjust the URC-200 (V2) for the following:
FM, LO POWER, PT, SCN OFF, BCN OFF
To configure presets, refer to Paragraph 4.4.6.
6. Transmitter FM PT Deviation and Distortion Measurements:
a. Set the presets on both the URC-200 (V2) and the R2600 to channel 01. Verify the URC-
200 (V2) is in the LO POWER mode.
b. Key the transceiver into the R2600 test set and read the FM deviation on the R2600
screen. Verify compliance with Table 1. In keying the transceiver the PTT line, pin F,
will be grounded.
c. Depress the DISP key on the R2600 front panel and move the cursor to the Meter position
and press the "EXT DIST" soft key.
NOTE
The “more” soft key may have to be depressed for the “EXT DIST” soft
key to be displayed.
d. Read the FM distortion on the R2600 screen and verify compliance with Table 1.
e. Depress the DISP key on the R2600 front panel and move the cursor to the Meter position
and press the "RF DISPLAY" soft key.
NOTE
The “more” soft key may have to be depressed for the “RF DISPLAY” soft
key to be displayed.
f. On both the URC-200 (V2) and the R2600 repeat steps A through E for preselect
channels 2 through 9 and channel 0 on the URC-200 (V2) with the R2600 set on preset
channel 10.
