General Dynamics URC-200 (V2) User Manual

General Dynamics C4 Systems URC-200 (V2)
142
Software version determination.
The warp adjustment procedure applies only to URC-200(V2) radios with software
version 1.6 and later. The software version can be checked two ways:
Power On Method:
The current software version is always displayed for a short time upon power-on
in the URC-200(V2) transceivers. Turn on power to the radio while observing the
display. The first screen will show the software version in the following format:
The display indicates that the software version is 01.06.00 (that is, version 1.6).
Remote Interrogation Method:
1. Connect the radio to a PC running a terminal emulation application such as
HyperTerminal configured in accordance with
Paragraph 4.6.
2. Type ?08 and the radio will return with a message similar to the following:
VC 98-P42306K V0106 Month Day Year Time
In this example V0106 indicates the current software version – 1.6. See also
Table 13
for additional information about queries.
If your radio has an older version of software installed contact General Dynamics support
for information concerning the Warp command.

General Dynamics URC-200 (V2) Specifications

General

Brand	General Dynamics
Model	URC-200 (V2)
Category	Transceiver
Language	English
