Table 13 – Transceiver Status Inquire Commands (Continued)
CODE NAME DESCRIPTION
?74
Transceiver
Control Modes
Value is returned in the form: “q.00a.01b.02c.03d”
a = 0 if transceiver in old RF card mode.
= 1 if transceiver in new RF card mode.
b = 0 if PT & CT are channel specific.
= 1 if PT & CT are global.
c = 0 if CT squelch control is static.
= 1 if CT squelch control is dynamic.
d = 0 if scan stops after a PTT press/release.
= 1 if scan continues after a PTT press/release
?75
Timing and Delay
Parameters
Value is returned in the form: “^.00aaa.01bbb”
aaa = DVI Shutdown Time (obsolete)
bbb = PTT Squelch Delay In 10 ms units)
?76
Squelch Detect
Parameters
Value is returned in the form: “w.0aaa.1bbb.2ccc .3ddd.4eee.5fff”
aaa = 30 to 90 MHz squelch level scalar
bbb = Carrier level slope scalar
ccc = Noise level slope scalar
ddd = Squelch level offset
eee = Squelch pot slope scalar
fff = Squelch threshold offset
?77 to
?79
Reserved
?80 to
?85
Deviation Values
Returns value in the form “Fxxx”
xxx = current value of that variable.
?86
Read PA-PATH
discrete
Returns values in the form: “Dx”.
x = 0 if PA-PATH discrete low,
x = 1 if PA-PATH discrete high.
?87
Read muxed
analog values
Returns value in the form: “abbbcccdddeeefff”
bbb = CAL_DET_CTRL,
ccc = B3_CAL_DET_CTRL,
ddd = B3_LOCK_DET_CTRL,
eee = B3_TONE_DET_CTRL,
fff = LOCK_DET_CTRL.
?88
Read analog
values
Returns value in the form: “bxxxcccdddeeefff”
xxx = A2D_OVERTEMP,
ccc = A2D_VOL_POT,
ddd = A2D_SQL_NL,
eee = A2D_SQL_CL,
fff = A2D_SQL_POT.
?89
Aviation Mode
Returns value in the form: “!n”
n=0 Disable Aviation Mode
n=1 Enable Aviation Mode
