Introduction Operator Manual
G1900™
© Genmega 2011
1.7
1.2.5 Main Control Board
Samsung S3C2440AL-40 RISC 32-bit CPU
64 MB RAM
WinCE™ 5.0 Operating System
Modem: 56,000 bps dial-up modem
TCP/IP Ethernet connection - Onboard SSL
Electronic Journal: 40,000 transactions
Battery back-up for set-up parameters (NVRAM)
Real time clock
1.2.6 Operating Environment
POWER REQUIREMENTS
110/220 VAC ± 10%, 50/60 Hz, 145 Watts
POWER CONNECTIONS
For warranty purposes, Genmega requires the 1900™ series ATM be connected to a
dedicated power circuit (5amp recommended). This circuit must consist of line,
neutral, and ground leads connected directly to the power circuit breaker panel. This
circuit should not be shared with any other equipment. Use of a surge protector or
uninterruptible power supply is recommended.
PHONE LINE REQUIREMENTS
The Genmega G1900 must be connected to a dedicated analog phone line. This line
must be a direct-dial analog line. It is important to disable any voice-mail included
on that phone line as it will cause the ATM not to dial out. This line should not be
shared with any other equipment at the location. Use of shielded (CAT5) phone
cable is also recommended for best performance and to reduce the chance of
interference. ‘Digital’ phone lines are NOT supported.
NETWORK (TCP/IP) REQUIREMENTS
For connection to processor via TCP/IP, use an Ethernet Patch-Cable (not included).
The ATM must connect to a device (Router) that can provide DHCP support unless a
static IP address is assigned by the service provider. It is recommended the ATM
connect to a broadband router (Linksys, Netgear, Belkin) or similar device rather
than directly to a Cable/DSL modem. For advanced or corporate networks, provide
the IT staff with ATM Host IP address and Host Port information (available from your
ISO).
TEMPERATURE
In storage : 32°F - 123°F (0°C ∼ 49°C)
While operating : 40°F - 95°F (5°C ∼ 35°C)
HUMIDITY
In storage : 10% < RH < 90%, non-condensed
While operating : 15% < RH < 85%, non-condensed
