GeoMax Zoom 30 series User Manual

Zoom | 112Applications
SETOUT Enter the set out elements for the target points to be set out relative to the
reference line.
Next step
Press OK to proceed to measurement mode.
Field Description
Line Longitudinal offset: Positive if set out point is further away from
the reference line.
Offset Perpendicular offset: Positive if set out point is to the right of the
reference line.
Z Height offset: Positive if set out point is higher than the reference
line.
