Applications Zoom | 123
Next step
Press OK to proceed to measurement mode.
Equal The misclosure will be equally distributed between
all sections.
Start Arc All of the misclosure will be added to the first arc-
section.
Arc
Length
For set out arc: The length of the arc-segment to set out.
Chord
Length
For set out chord: The length of the chord to set out.
Angle For set out angle: The angle around the center point of the arc,
of the points to be set out.
Line For set out arc, chord and angle: Longitudinal offset from the
reference arc. This is calculated by the arc length, chord length
or angle and the selected misclosure distribution.
For set out point: Longitudinal offset from the reference arc.
Offset Perpendicular offset from the reference arc.
Field Description
