Data Management Zoom | 167
)
All jobs will be stored in the backup folder created on the USB memory stick.
The job data will be stored as individual database files for each job, which can
then be imported again. Refer to "10.3 Importing Data".
Exportable job
data formats
Job data can be exported from a job in a variety of file types. A format can be
defined in GGO Format Manager. Refer to the online help of GGO for informa-
tion on creating format files.
RS232 example job data output
Within the Data Type setting Observations, a data set could be shown as
follows:
11....+00000D19 21..022+16641826 22..022+09635023
31..00+00006649 58..16+00000344 81..00+00003342
82..00-00005736 83..00+00000091 87..10+00001700
GSI-IDs GSI-IDs continued
11 Pt 41-49 Codes and attributes
21 Horizontal direction 51 ppm [mm]
22 Vertical angle 58 Prism constants
25 Orientation 81-83 (E, N, H) Target point
31 Slope distance 84-86 (E, N, H) Station point
32 Horizontal distance 87 Reflector height
