Zoom | 182Calibration
5 Press REC to measure to the target point.
6Either:
• Press OK to save the new calibration data, or
• Press ESC to exit without saving the new calibration data.
Messages The following are important messages or warnings that may appear.
)
The old and new calculated values are displayed.
Messages Description
VA-angle not suitable
for adjustment !
The vertical angle deviates from the required hori-
zontal / line-of-sight, or in face II the vertical angle
deviates by more than 5° from the target point. Aim
at the target point with an accuracy of min. 5°.
Confirmation of the message required.
Results out of toler-
ance. Previous values
retained !
Computed values out of tolerance. The previous
values are retained and measurements should be
repeated. Confirmation of the message required.
HA-angle not suitable
for adjustment !
Horizontal angle in face II deviates by more than 5°
from the target point. Aim on the target point with
an accuracy of min. 5°. Confirmation of the
message required.
