8GS15
plus
Connect to the Plotter
CAUTION: Be sure power is turned off and the power cord is
unplugged at both the GRAPHIX ADVANTAGE and the
plotter.
1. Insert the 9-pin connector at the end of the RS-232 cable into the 9-
pin RS-232 connector on the back of the GRAPHIX ADVANTAGE.
This connector is normally labeled Plotter or COM Port 2.
2. Carefully align all pins. Use the connector thumb screws to secure
the cable to the system.
3. Insert the 25-pin connector at the end of the RS-232 cable into the
25-pin RS-232 connector on the back of the plotter.
4. Carefully align all pins. Secure the cable to the plotter with the
connector thumb screws.
Note: If a plotter is already installed in the PLOTTER port on the
GRAPHIX ADVANTAGE, use the TABLET port to install a second
plotter.
Communication Parameters
If you are connecting the GS750
plus
to a system other than the
GRAPHIX ADVANTAGE, the plotter uses these RS-232
communication parameters:
Communication Parameters
9600 Baud
No Parity
8 Data Bits
1 Stop Bit
Xon/Xoff Flow Control
